The Magritek NMR Core Analyzer’s Standard Core Lab Configuration

Topics Covered

Introduction
NMR Rock Core Analyzer
Magritek P35 Probe
Magritek Q-Switched P54 Probe
Fully Integrated Software
Conclusion
About Magritek

Introduction

Magritek offers innovative products in the field of NMR and MRI, designed specifically for industries and research laboratories. Most popular products in this category include the Magritek Q-Switched P54 probe for flexible high performance measurements of cores with 1.5” diameter, the high-resolution P35 probe to measure hard shales and cores and the 2MHz NMR rock core analyzer for specific measurements on Standard Core Lab Configuration (SCAL).

This article provides a detailed explanation of the products listed above.

NMR Rock Core Analyzer

The 2 MHz NMR rock core analyzer (Figure 1) is suitable for the measurement of FFI, permeability, T1 distribution, T2 T2 distribution, BVI and CBW.

Figure 1. 2 MHz NMR rock core analyzer

Given below are the key features of the NMR rock core analyzer:

  • User-friendly software
  • 60µs echo time for hard core and shale measurement
  • Thermally isolated and controlled magnet ensures measurement stability

There are two types of probes available from Magritek. Magritek P35 probe has short TE for tight cores and shales and Magritek Q-Switched P54 probe is flexible enough for standard samples.

Magritek P35 Probe

Magritek’s P35 probe can be used for measuring T2 core values with high resolution. It is capable of resolving short T2 values of cores with tiny pores in <0.1ms with 60µs TE. The P35 offers high signal-to-noise ratio (SNR) and rapid measurements. The shale measurements carried out using the Magritek P35 probe is shown in Figure 3.

Figure 2. Magritek P35 probe

Figure 3. Shale measurement performed using the Magritek P35 probe at 60µs TE.

Specifications of the Magritek P35 probe are as follows:

PARAMETERS SPECIFICATION
Minimum echo time 60 µs
Minimum SNR at 60 µs TE (4 scans, 10 ml H2O) 150
Minimum SNR at 100 µs TE (4 scans, 10 ml H2O) 260
Maximum core diameter 1”
Maximum core length 2”

Magritek Q-Switched P54 Probe

The Magritek Q-Switched P54 probe (Figure 4) is specifically designed for high performance and rapid measurements of cores with 1.5” diameter. With TE values of 100µs and high SNR, the P54 probe can resolve T2 values with optional overburden up to135°C and 5000 PSI. The probe is flexible and provides 100µs echo time. Figure 5 provides the measurements obtained using the P54 probe at TE 100µs.

Figure 4. Magritek Q-Switched P54 probe

Figure 5. Range of measurements obtained using the P54 probe at TE 100µs.

Specifications of the Magritek Q-Switched P54 probe are as follows:

PARAMETERS SPECIFICATION
Minimum echo time 100 µs
Minimum SNR* at 100 µs TE (4 scans, 10 ml H2O) 160
Maximum core diameter 1.5”
Maximum core length 2.5”

Fully Integrated Software

All the analytical systems from Magritek have fully integrated hardware and software. The 2 MHz NMR rock core analyzer is equipped with RCA software that enables flexible standard SCAL NMR measurements such as T2 distribution, porosity and permeability.

Moreover, the data obtained from the system are presented in Excel-compatible format for value addition and custom reporting. The integrated software is user-friendly, and has s simple interface with measurement queuing and stable parameter settings.

Conclusion

Magritek’s next-generation analytical solutions allow fast, flexible and high performance NMR measurements of SCAL, CBW, T2 T2 distributions, porosity, permeability, etc.

About Magritek

Founded in 2004, Magritek is an advanced technology company exporting from Germany and New Zealand to customers all over the world. The initial technology and IP used in Magritek products was developed by research teams at RWTH Unviersity, Germany, and Massey University and Victoria University of Wellington in New Zealand. Today, Magritek provides complete NMR and MRI system solutions for the oil and gas industry, as well as components and subsystems suitable for research laboratories and education.

This information has been sourced, reviewed and adapted from materials provided by Magritek.

For more information on this source, please visit Magritek.
