Apr 16 2018
Geologists have found out that certain magmas split into two distinct liquids, one of which is highly rich in iron. Their conclusions can help to locate new iron ore deposits for mining.
The samples were placed in small golden capsules – with a melting point of 1,064 °C – and subjected to temperatures of 1,000-1,040 °C and one thousand times the atmospheric pressure of Earth. (Image credit:© Lennart A. Fischer)
Iron ore is mined in approximately 50 countries, with Australia, Brazil, and China leading the list of largest producers. It is typically used to make the steel objects like paper clips and kitchen appliances as well as supporting beams in skyscrapers.
A majority of iron ore deposits are found in sedimentary rocks. Others are mined in volcanic complexes such as Kiruna in Sweden and El Laco in Chile. These iron ore deposits, called Kiruna-type deposits, make up for about 10% of the worldwide production of iron, yet no one is aware of how they are formed.
An international group of researchers from institutions including KU Leuven, Leibniz University Hannover, and ULiège presented the first evidence in Nature Communications that these iron ore deposits are produced when magma splits into two distinct liquids.
“Previous studies have always focused on the texture or the composition of natural rocks. We were the first to actually reproduce magmas in the lab such as the ones found in El Laco, Chile,” says last author Olivier Namur from the Department of Earth and Environmental Sciences at KU Leuven, Belgium.
“We wanted to reproduce the conditions found in magma chambers, where molten rock accumulates when it cannot rise to the surface of the Earth. This is also where the iron ore deposits beneath volcanoes are formed, so reproducing the temperature and pressure of the magma chambers seemed well worth examining.”
“That’s why we produced a mixture of iron-rich ore samples and typical lavas surrounding Kiruna-type deposits. This created a bulk magma composition that we believe exists in the deep magma chamber beneath volcanoes. We placed the mixture in a furnace and raised the temperature to 1,000-1,040 °C. We also increased the pressure to about 1000 times the atmospheric pressure of Earth. These are the conditions of a magma chamber.”
“We were surprised to find that, under these conditions, the magma split into two separate liquids. This process is known as immiscibility. Just think of what happens when oil spills into the ocean: the water becomes streaked with oil because oil and water cannot mix.”
“One of these liquids contained a lot of silica, whereas the other was extremely rich in iron – up to 40% – and phosphorus. When this iron-rich liquid starts to cool down, you get iron-phosphorous Kiruna-type ore deposits.”
“This is the first evidence that immiscibility is key to the formation of iron ore deposits such as the ones mined in El Laco. If we’re right, these findings may help to find new iron ore deposits. This is necessary to keep up with the global demand for iron: recycling alone is not enough yet. And if you want to know where to look for iron ore, you have the understand how the deposits are formed.”
