Watch this webinar titled, 3D Crystallographic Tomography: A Revolutionary New Lab Technique to Image Grain Microstructure on-demand now.
About this webinar
In this webinar, two experts from the field of 3D X-ray microscopy and metals research respectively, will introduce the groundbreaking laboratory based non-destructive 3D crystallographic grain mapping technique called diffraction contrast tomography (DCT) and present compelling applications examples on a wide variety of materials.
Previously only accessible at the synchrotrons, this revolutionary technique is now within the reach of every academic and industrial researcher and can provide a deeper insight into the 3D crystallographic microstructure of samples ranging from metals and alloys, ceramic and geomaterials. New generation lab-based DCT now unlocks access to massive sample volumes, up to three orders of magnitude larger than traditional 3D-EBSD methods and delivers true sample representivity. Coupled with correlated microscopy workflows, lab-based DCT delivers the most comprehensive story of any polycrystalline sample.
Key learning objectives:
- How X-rays can be used for mapping crystallographic grain microstructure in 3D non-destructively in a home laboratory
- Significance of true sample representivity and how new non-destructive methods can address this critical challenge
- How the destructive and non-destructive approaches can be combined to gain unique insights into a materials science sample
- What future directions lab-based DCT and other grain mapping workflows hold for materials research?
