A new study reveals how tracking the fractal signature of microseismic activity can identify hidden roof damage and predict hazardous rock bursts, providing miners with crucial days to act before disaster strikes.
Image credit: Pedal to the Stock/Shutterstock.com
In a recent article published in the journal Scientific Reports, researchers developed an effective and quantitative early-warning mechanism for rock bursts, using the self-similar and scale-invariant properties of microseismic energy distributions as captured through correlation-integral-based calculations of fractal dimensions and a specialized 3D sliding-window analysis method.
Limits of Traditional Mine Monitoring
Deep coal mining environments are characterized by high stress concentrations and complex geological conditions, often resulting in unstable surrounding rock and sudden failure events, such as rock bursts. Traditional monitoring approaches have included tracking seismic energy, event frequency, and electromagnetic signals, which offer some predictive insight but lack consistency and quantifiability.
The application of fractal geometry in geotechnical engineering has long provided a framework for describing irregular and self-similar patterns observed in natural systems. Several prior studies have demonstrated the fractal nature of rock fragmentation, joint surface roughness, and damage evolution in rocks subjected to stress.
Researchers have also applied fractal analysis to microseismic data within mining contexts, establishing relationships between fractal characteristics and microscopic damage mechanisms. These studies form the theoretical basis for considering fractal dimensions as potential quantitative indicators for rock stability and failure. However, existing statistical indicators often fail to provide unified or quantitative early-warning thresholds, highlighting the need for a more robust fractal-based metric.
How the Mine Was Monitored
The study involves detailed microseismic monitoring within a coal mine in Shaanxi Province, China, where the geological setting is known to experience rock bursts. The mining area features a relatively thick, gently inclined seam buried at substantial depth, with overlying strata composed predominantly of siltstone and sandstone. The internal damage processes associated with extraction activities, coupled with significant structural activity in the roof strata, make the site suitable for studying the evolution of microseismic signals.
The study aims to establish a relationship between microseismic energy and its fractal characteristics through quantitative analysis. The researchers deploy a three-dimensional microseismic monitoring system that records vibration events with energies greater than 100 Joules, categorized within a broad frequency range. This data collection provides a detailed temporal and spatial record of seismic activity.
To analyze the fractal nature of the microseismic events, the authors employ the concept of fractal dimension, which quantifies the complexity and self-similarity of the distribution pattern of seismic source points. Specifically, they interpret the spatial distribution of energy source points as a discrete point set and utilize the correlation integral method to compute the fractal dimension derived from an integral expression that links rock damage, energy dissipation, and event distribution.
This involves overlaying grids of various scales on the microseismic event map and counting the number of boxes containing energy sources at each scale as part of a later spatial-temporal sliding-window evaluation. The fundamental fractal dimension is extracted from the correlation between monitored event energies and scale radii.
The relationship between the number of occupied boxes and the scale size is plotted in a log-log graph, with the slope providing the fractal dimension. A 3D sliding rectangular window, progressively enlarged from 20 × 20 × 4 m to 100 × 100 × 20 m, is then moved along both the spatial and temporal axes to derive a continuous spatiotemporal evolution curve of the fractal dimension.
Signals Before Failure
The findings reveal that the microseismic energy distribution within the mine exhibits clear fractal characteristics, with the calculated fractal dimensions providing insights into the damage state of the surrounding rock. Four distinct stages of evolution were identified: stable, early-warning, deformation, and re-stabilization, each characterized by specific fractal-dimension ranges and behaviors.
During the stable period, the fractal dimension remains relatively high, often above 2.5, indicating that microseismic events are highly dispersed and disordered, characteristic of a stable rock mass. As stress accumulates, a transitional early-warning phase emerges, marked by a rapid decrease in fractal dimension, signaling the transition from a dispersed to a more concentrated seismic event pattern.
This reduction in fractal dimension, typically dropping below 1.0 during the deformation stage, signifies a clustering of microseismic activity: an indicator of imminent failure. The progression from the stable phase to the deformation stage aligns with increased energy release and concentrated seismicity, consistent with the physical process of damage evolution within the rock. Notably, these changes in fractal dimensions precede the occurrence of a rock burst, establishing them as potential reliable precursors.
The authors discuss the physical significance of these findings, emphasizing that the diminishing fractal dimension reflects the accumulation of internal damage, fault coalescence, and the formation of macrofractures. This transition from high to low fractal dimensions reflects the progression from a stable structural condition to a critical state where failure is imminent.
The study demonstrates that monitoring the temporal evolution of the fractal dimension provides an effective means to anticipate rock burst events, offering a more consistent indicator than traditional statistical parameters, which often lack consistency. The spatial variation of the fractal dimension also identifies zones of heightened instability, with local minima corresponding closely to observed rock burst events and roof collapse locations.
Impacts For Mining Safety
The study successfully establishes a link between microseismic energy distribution and the fractal characteristics of surrounding rock damage in a deep coal mining context. This research offers valuable insights for the field of mining engineering, emphasizing the integration of fractal theory into microseismic monitoring systems to enhance the reliability of early warning methods.
Its implications extend to improving safety standards, optimizing mining operations, and reducing the risks associated with deep mining activities. However, sensitivity to sensor layout, noise-filtering thresholds, and roof-management strategies may influence the stability and applicability of fractal-dimension calculations, limiting their use.
Ultimately, the application of fractal analysis stands to transform current practices by providing a deeper understanding of the complex damage processes within surrounding rock masses, fostering safer and more efficient mining environments.
Download your PDF copy now!
Journal Reference
Wu Y., Zhu Z., et al. (2025). Early-warning method for rock bursts based on the fractal characteristics of microseismic source. Scientific Reports 15, 38871. DOI: 10.1038/s41598-025-22737-1, https://www.nature.com/articles/s41598-025-22737-1
