Light Duty Pedestal Boom – the RB600 LD from Atlas Copco

The RB600 LD is a two-section boom which is suitable for use in light duty jaw crusher applications. It ensures maximum horizontal reach of about 5.2 m.

Key Features

The key features of the RB600 LD are:

  • The RB600 LD features AutoLube automatic boom lubrication system for maximizing the boom life expectancy and ensuring low maintenance
  • SwingDevice with 140 degree rotation is provided for easily maintaining the RB600 LD
  • SB302, SB452 or SB552 breaker for ensuring optimized productivity.

Specifications

The specifications of the RB600 LD are given in the following table.

Duty Light
Recommended breaker weight 300-550 kg
Power pack 35-55 kW
Horizontal reach (breaker vertical), max 5.2 m
Vertical reach (excluding breaker), max 3.3 m
Radial raking depending on reach, max at 2 m 450-1200 kg
Operating mass excluding breaker, Power pack and control console 2400 kg
Swing 140
Application Jaw crusher
Number of boom sections
2
