Light Duty Pedestal Boom from Atlas Copco – RB650 LD

Atlas Copco offers the RB650 LD which is suitable for use in light duty jaw crusher applications. It is a two-section boom, and has a horizontal reach of up to 5.7 m.

Key Features

The key features of the RB650 LD are:

  • SB302, SB452 or SB552 breaker is provided in the RB650 LD for ensuring high productivity
  • Optional AutoLube automatic boom lubrication system is available for increasing the service life of the boom and ensuring less maintenance
  • SwingDevice with 140 degree rotation is available for easy maintenance

Specifications

The specifications of the RB650 LD are given in the following table.

Duty Light
Recommended breaker weight 300 - 550 kg
Power pack 35 - 55 kW
Horizontal reach (breaker vertical), max 5.7 m
Vertical reach (excluding breaker), max 3.3 m
Radial raking depending on reach, max at 2 m 450 - 1200 kg
Operating mass excluding breaker, Power pack and control console 2480 kg
Swing 140
Application Jaw crusher
Number of boom sections
2
