RB600 MD Pedestal Boom for Medium Duty Jaw Crushing from Atlas Copco

Atlas Copco offers the RB600 MD which is a two-section boom. It can be used in medium duty jaw crusher applications. It achieves maximum horizontal reach of about 5.4 m.

Key Features

The key features of the RB600 MD are:

  • It includes MB750, MB1000 or MB1200 breaker for achieving high productivity
  • SwingDevice with 140 degree rotation for ensuring easy maintenance
  • Optional AutoLube automatic boom lubrication system for increasing the service life of the boom and ensuring low maintenance.

Specifications

The specifications of the RB600 MD are given in the following table.

Duty Medium
Recommended breaker weight 750-1200 kg
Power pack 55 kW
Horizontal reach (breaker vertical), max 5.4 m
Vertical reach (excluding breaker), max 1.4 m
Radial raking depending on reach, max at 2 m 1000-2500 kg
Operating mass excluding breaker, Power pack and control console 5860 kg
Swing 140
Axial raking 1500 kg
Application Jaw crusher
Number of boom sections 2
