RB300 XD: Extreme Duty Pedestal Boom by Atlas Copco

The RB300 XD available from Atlas Copco is a two section extreme duty pedestal boom, which is exclusively designed for small size mobile grizzly applications. The equipment incorporates the SlewDevice with 270 degree rotation and has a horizontal reach of approximately 2.7 m.

Key Features

The product features of the RB300 XD pedestal boom are:

  • SB302 or SB202 breaker offers improved productivity
  • Hydraulic joystick controls allow accurate movement
  • SlewDevice with 270 degree rotation provides optimum reach and ease of maintenance

Specifications

The specifications of the RB300 XD pedestal boom are provided in the table below:

Duty Extreme
Application Grizzly
Horizontal reach (breaker vertical), max 2.7 m
Vertical reach (excluding breaker), max 0.63 m
Swing 270
Number of boom sections 2
Power pack 35 kW
Radial raking depending on reach, max at 2 m 110 - 220 kg
Axial raking 450 kg
Operating mass excluding breaker, Power pack and control console 1080 kg
Recommended breaker weight 200 - 300 kg
Hydraulic breaker
SB202, SB302
